Phoenix Contact -1729131 -PCB terminal block - MKDSN 1,5/ 3-5,08 - TB-2517-D
₹32.00
SPQ
100 MOQ
10 Visible Manufacture Name
Phenix Contatct Visible Manufacturer’s code
MKDSN 1,5/ 3-5,08 - 1729131 Weight (gm)
0.002918 Brand/MFR No
Phoenix Contact/MKDS 5/ 3-7,62 - 1729131Stock Available
360 Choose Quantity
Product Details
PCB terminal block, nominal current: 13.5 A, rated voltage (III/2): 400 V, nominal cross section: 1.5 mm2, number of potentials: 3, Number of rows: 1, Number of positions per row: 3, product range: MKDSN 1,5, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, mounting: Wave soldering, conductor/PCB connection direction: 0°, color: green, Pin layout: Linear pinning, Solder pin [P]: 3.5 mm, type of packaging: packed in cardboard.
Get the high-quality PCB terminal block - MKDSN 1,5/ 3-5,08 at the best price in India.
PCB terminal block - MKDSN 1,5/ 3-5,08 Product Properties:-
| Type | PC termination block |
| Number of positions | 3 |
| Number of connections | 3 |
| Number of rows | 1 |
| Number of potentials | 3 |
| Pin layout | Linear pinning |
PCB terminal block - MKDSN 1,5/ 3-5,08 Electrical Properties:-
| Maximum load current | 13.5 A |
| Rated voltage (II/2) | 630 V |
| Rated voltage (III/2) | 400 V |
| Rated surge voltage (II/2) | 4 kV |
| Rated surge voltage (III/2) | 4 kV |
| Rated surge voltage (III/3) | 4 kV |
| Nominal voltage UN | 250 V |
| Nominal current IN | 13.5 A |
| Nominal current IN | 13.5 A |
To know more about all latest Products of PCB Terminal Blocks you can visit at www.campuscomponent.com
