Phoenix Contact-1711738 -Printed circuit board terminal - MKDS 3/ 3-5,08 - 1711738 - TB-2347-D
₹32.00
SPQ
100 MOQ
10 Visible Manufacture Name
Phoenix Contact Visible Manufacturer’s code
MKDS 3/ 3-5,08 - 1711738 Weight (gm)
0.00577 Brand/MFR No
Phoenix Contact/MKDS 3/ 3-5,08- 1711738Stock Available
3000 Choose Quantity
Product Details
PCB terminal block, nominal current: 24 A, rated voltage (III/2): 400 V, nominal cross section: 2.5 mm2, number of potentials: 3, Number of rows: 1, Number of positions per row: 3, product range: MKDS 3, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, mounting: Wave soldering, conductor/PCB connection direction: 0 °, color: green, Pin layout: Linear pinning, Solder pin [P]: 5 mm, type of packaging: packed in cardboard. The article can be aligned to create different nos. of positions.
Product Properties:-
| Type | PC terminal block can be aligned |
| Number of positions | 3 |
| Number of connections | 3 |
| Number of rows | 1 |
| Number of potentials | 3 |
| Pin layout | Linear pinning |
Electrical Properties:-
| Maximum load current | 28 A (with 4 mm² conductor cross section) |
| Rated voltage (II/2) | 630 V |
| Rated voltage (III/2) | 400 V |
| Rated surge voltage (II/2) | 4 kV |
| Rated surge voltage (III/2) | 4 kV |
| Rated surge voltage (III/3) | 4 kV |
| Nominal voltage UN | 250 V |
| Nominal current IN | 24 A |
| Nominal current IN | 24 A |
Attachment:-
