Phoenix Contact -1757022 -Printed-circuit board connector - MSTB 2,5/ 3-ST-5,08 AU - CO-2530-D
₹90.00
Out of stock
Product Details
PCB connector, nominal cross section: 2.5 mm2, color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Gold, type of contact: Female connector, number of potentials: 3, Number of rows: 1, Number of positions per row: 3, number of connections: 3, product range: MSTB 2,5/..-ST, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, conductor/PCB connection direction: 0°, Locking clip: - Locking clip, plug-in system: CLASSIC COMBICON, Locking: without, mounting: without, type of packaging: packed in cardboard.
Get the high-quality Printed-circuit board connector - MSTB 2,5/ 3-ST-5,08 AU at the best price in India.
Printed-circuit board connector - MSTB 2,5/ 3-ST-5,08 AU Product Properties:-
| Type | Standard |
| Number of positions | 3 |
| Number of connections | 3 |
| Number of rows | 1 |
| Connector system | CLASSIC COMBICON |
| Mounting flange | no |
| Number of potentials | 3 |
Printed-circuit board connector - MSTB 2,5/ 3-ST-5,08 AU Electrical Properties:-
| Maximum load current | 12 A (with a 2.5 mm² conductor cross section) |
| Rated voltage (II/2) | 630 V |
| Rated voltage (III/2) | 320 V |
| Rated surge voltage (II/2) | 4 kV |
| Rated surge voltage (III/2) | 4 kV |
| Rated surge voltage (III/3) | 4 kV |
| Nominal voltage UN | 250 V |
| Nominal current IN | 12 A |
| Nominal current IN | 12 A |
