Phoenix Contact PCB connector - MSTB 2,5/ 8-STF-5,08 - CO-2879-D

Phoenix Contact -1778043 - PCB connector - MSTB 2,5/ 8-STF-5,08 - CO-2879-D

₹550.00
Out of stock
SPQ
100
MOQ
1
Visible Manufacture Name
Phoenix Contact
Visible Manufacturer’s code
MSTB 2,5/ 8-STF-5,08 - 1778043
Weight (gm)
0.015kg
Brand/MFR No
Phoenix Contact/MSTB 2,5/ 8-STF-5,08 - 1778043
Add to Cart
Product Details
 PCB connector - MSTB 2,5/ 8-STF-5,08 Specifications and features:-
  • nominal cross section: 2.5 mm2
  • color: green, nominal current: 12 A
  • rated voltage (III/2): 320 V
  • contact surface: Gold
  • type of contact: Female connector
  • number of potentials: 8, number of rows: 1
  • number of positions: 8
  • number of connections: 8
  • product range: MSTB 2,5/..-STF
  • pitch: 5.08 mm
  • connection method: Screw connection with tension sleeve
PCB connector - MSTB 2,5/ 8-STF-5,08 advantages:
  • Gold-plated contacts ensure transfer quality remains stable over the long term
  • Well-known connection principle allows worldwide use
  • Low temperature rise, thanks to maximum contact force
  • Screwable flange for superior mechanical stability
  • Allows connection of two conductors
To know more about all latest Products of  Electronics Housing you can visit at  www.campuscomponent.com
