PCB header - MSTB 2,5/ 2-G-5,08 - CO-2532-D
₹25.00
SPQ
100 MOQ
10 Visible Manufacture Name
Phoenix Contact Visible Manufacturer’s code
MSTB 2,5/ 2-G-5,08 - 1759017 Weight (gm)
0.0006kgStock Available
500 Choose Quantity
Product Details
PCB headers, nominal cross section: 2.5 mm2, color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Tin, type of contact: Male connector, number of potentials: 2, Number of rows: 1, Number of positions per row: 2, number of connections: 2, product range: MSTB 2,5/..-G, pitch: 5.08 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.5 mm, plug-in system: CLASSIC COMBICON, Pin connector pattern alignment: Standard, Locking: without, mounting: without, type of packaging: packed in cardboard.
PCB header - MSTB 2,5/ 2-G-5,08 Product Properties:-
| Type | Standard |
| Number of positions | 2 |
| Number of connections | 2 |
| Number of rows | 1 |
| Connector system | CLASSIC COMBICON |
| Mounting flange | without |
| Number of potentials | 2 |
| Pin layout | Linear pinning |
PCB header - MSTB 2,5/ 2-G-5,08 Electrical Properties:-
| Maximum load current | 12 A |
| Rated voltage (II/2) | 400 V |
| Rated voltage (III/2) | 320 V |
| Rated surge voltage (II/2) | 4 kV |
| Rated surge voltage (III/2) | 4 kV |
| Rated surge voltage (III/3) | 4 kV |
| Nominal voltage UN | 250 V |
| Nominal current IN | 12 A |
| Nominal current IN | 12 A |
