HOEPRF Rx Development module CMT2210LH-DM - WI-3345-D
Out of stock
SPQ: 1, MOQ:1
₹1,350.00
SPQ
1 MOQ
1 Visible Manufacture Name
HopeRF Visible Manufacturer’s code
CMT2210LH-DM Weight (gm)
0.025 Brand/MFR No
HOPERF/CMT2210LH-DM Product Details
Get the high-quality Rx Development module CMT2210LH-DM at the best price in India.
CMT2210LH is a low power, high performance OOK RF receiver. It is suitable for ISM band 315MHz/433.92MHz wireless applications. The CMT2210LH is a real plug and play chip without the register configuration or manual tuning. By selecting 19.7029MHz or 27.1412MHz crystal, the chip can operate at 315MHz or 433.92MHz. This chip supports the symbol rate range of 1~5 Kbps and is ideal for pairing with the low end transmitter based on the encoder or MCU.
CMT2210LH-DM Specifications:-
- Working frequency：315MHz/ 433.92MHz
- OOK demodulation
- Symbol rate：1.0 - 5.0 kbps
- Sensitivity：-109 dBm（3.0 kbps），0.1％BER
- Receiver bandwidth：330kHz
- Image rejection ratio：30dB
- Maximum input signal：10 dBm
- Run independently. Input from the antenna. Output the data.
- Configure without the register
