AIT Semiconductor A4714MS10VR - IC-3452-D

AIT Semiconductor A4714MS10VR - IC-3452-D

₹30.00
SPQ: 4000, MOQ:1, Product Package: PSOP8
SPQ
4000
MOQ
1
Visible Manufacture Name
AIT Semiconductor
Visible Manufacturer’s code
A4714MS10VR
Brand/MFR No
AIT Semiconductor/A4714MS10VR
Quantity
Add to Cart
Product Details
Get the high-quality AIT Semiconductor A4714MS10VR  at the best price in India.

The A4714 is a dual, low on-resistance, low voltage, bidirectional, single-pole/double-throw (SPDT) CMOS analog switches designed to operate from a single +1.8V to +5.5V supply. Targeted applications include battery powered equipment that benefit from low RON (0.5Ω) and fast switching speeds (tON = 16ns, tOFF = 15ns). The on resistance profile is very flat over the full analog signal range. This ensures excellent linearity and low distortion when switching audio signals.

AIT Semiconductor A4714MS10VR Specification:
  • Low voltage operation: 1.8V to 5.5V
  • Low on-resistance: 0.5Ω (TYP)
  • Low on-resistance flatness
  •  –3 dB bandwidth: 30 MHz
  • Fast switching time : tON="16ns," tOFF="15ns"
  • Rail-to-rail operation
  • Typical power consumption (<0.01μW)
  • TTL/CMOS compatible
  • Available in MSOP10 package
