A6120DR-50_LOW DROPOUT VOLTAGE REGULATOR-IC-621-D
Non-returnable
₹15.00
Out of stock
SPQ:,MOQ:1,Product Package:SOT 223 Package
Product Details
A6120 is a series of low power consumption, low dropout voltage regulator with a typical dropout voltage of 1.0V at 2A load current. A6120 can provide output value in the range of 1.2V~5.0V in 0.1V steps. It also can customized on command. Other than every voltage version can be used as an adjustable voltage version, with which desired voltage can be achieved by setting the values of two external resistors of the application circuitry. A6120 has well load transient response and good temperature characteristic, And it uses trimming technique to guarantee output voltage accuracy within±2%.
Get the high-quality A6120DR-50_LOW DROPOUT VOLTAGE REGULATOR at the best price in India.
A6120DR-50_Low Dropout Voltage Regulator Features:-
- Low Power Consumption:3.0uA (Typ.)
- Maximum output current : 2A
- Maximum input voltage: 18V
- Line regulation: 0.2% (Typical)
- Output Voltage Range:1.2V~5.0V (customized on command in 0.1V steps)
- Highly Accurate:±2%(±1% customized)
- Typical Dropout Voltage: 850mV@1.5A (VOUT=3.3V)
- Operation environment Temperature: -40°C~85°C
- Available in SOT-223 and TO-252 Packages
A6120DR-50_Low Dropout Voltage Regulator Applications:-
- Battery Charger
- Battery Powered equipment
- Post Regulators for Switching Supplies
- Reference Voltage Source Regulation after Switching Power
To know more about all latest Products of Voltage regulator you can visit at www.campuscomponent.com
