Puya Semiconductor Serial NOR Flash Memory PY25Q16LB-SSH-IR - ME-3840-D
Non-returnable
- Part Number Description- PY25Q16LB-SSH-IR
- Supply Voltage: 1.65V to 2V
- Interface: SPI (Single, Dual, Quad, QPI, DTR)
- SPI Modes Supported: Mode 0, Mode 3
- Page Program Size: 256 Bytes
- Sector Erase Size: 4KB
- Block Erase Sizes: 32KB / 64KB
- Full Chip Erase: Supported
- Security Registers: 3 × 1024 Bytes (OTP)
- Program/Erase Cycles: 100,000 Cycles
₹14.00
SPQ
4000 MOQ
1 Visible Manufacture Name
Puya Semiconductor Visible Manufacturer’s code
PY25Q16LB-SSH-IR Brand/MFR No
Puya Semiconductor/PY25Q16LB-SSH-IR Choose Quantity
Product Details
The PY25Q16LB is a serial interface Flash memory device designed for use in a wide variety of high-volume consumer-based applications in which program code is shadowed from Flash memory into embedded or external RAM for execution. The flexible erase architecture of the device, with its page erase granularity it is ideal for data storage as well, eliminating the need for additional data storage devices. The device also contains an additional 3*1024-byte security register with OTP lock (One-Time Programmable), which can be used for purposes such as unique device serialization, system-level Electronic Serial Number (ESN) storage, locked key storage, etc. Specifically designed for use in many different systems, the device supports read, program, and erase operations with a wide supply voltage range of 1.65V to 2.0V. No separate voltage is required for programming and erasing.
Get the high-quality Serial NOR Flash Memory PY25Q16LB-SSH-IR at the best price in India.
Serial NOR Flash Memory PY25Q16LB-SSH-IR Features:-
- Single 1.65 to 2.0V supply
- Serial Peripheral Interface (SPI) Compatible: Mode 0 and Mode 3
- Single, Dual, Quad SPI, QPI, DTR - Standard SPI: SCLK, CS#, SI, SO, WP#, HOLD# - Dual SPI: SCLK, CS#, IO0, IO1, WP#, HOLD# - Quad SPI: SCLK, CS#, IO0, IO1, IO2, IO3 - QPI: SCLK, CS#, IO0, IO1, IO2, IO3 - DTR: Double Transfer Rate Read
- Flexible Architecture for Code and Data Storage - Uniform 256-byte Page Program - Uniform 4K-byte Sector Erase - Uniform 32K/64K-byte Block Erase - Full Chip Erase
- Hardware Controlled Locking of Protected Sectors by WP# Pin
